KNX STACK

• The KNX protocol is a very complex and unique structure. This structure has its own controls as a working principle.

•

• Load procedure, flag procedure, priority procedures, system structures and procedures of related group addresses and Telegram structures, individual address, transport layer procedures, etc. It is a structure consisting of many more procedures such as
• Whether these controls comply with the procedures is determined by performing the necessary tests in the stack laboratory of KNX.

FIRST and ONLY KNX CERTIFIED IN TURKEY

B-STACK

B-STACK KULLANIMI

• Device design M.T. It is done with the program. M.T. In the program, the design is prepared with the external background (Static) and the draft created for B-STACK.
• Appropriate equipment is provided.
• Programming button and LED indicator algorithms also come with B-STACK software. It is sufficient to connect it to the relevant outputs of the microcontroller.
• M.T. The data map seen in the program (parameters to be changed in ETS) is transmitted with B-STACK variables. These values ​​can be easily retrieved and processed.
• Telegrams coming with B-STACK functions and software structure are automatically captured and the received data can be easily retrieved with the help of B-STACK variables.
• Without the need for any Telegram procedure, status or response telegrams can be sent with the functions in the B-STACK library.
• When sending status or response, the association between the group address and the group object is provided. Telegram can be sent easily by just typing group object number and value. B-STACK has the feature of matching group addresses within itself.
• There is no need to create algorithms for ETS commands such as Fully Download, Info, Partial Download, Reset, Unload. All provided by B-STACK.
• Behaviors after BUS commute (BUS Failure) are enough to be written into the generated B-STACK function.
